Gravelrings gravel grids
for strong, stable,
stone migration free

Gravel retention system

Beauxfort’s Gravelrings gravel driveway grid system creates a distinguished driveway that gives that all-important crunch-factor. The grids remain invisible beneath the surface as the system is designed to be overfilled, delivering porous, stable and dependable gravel driveway support for demanding use.

• Reduces project costs as the system requires less gravel demand and excavation than alternative systems

• Fast installation, Gravelrings gravel driveway grids come prepared in 1sqm tiles with a simple clipping mechanism making the system extremely efficient to lay

• Stops stone migration and patchy irregularities spoiling the beautiful aesthetic of gravel driveways

• Gravelrings gravel stabilisation system prevents gravel from slipping beneath the panels and lifting them up

Click here to download the Gravelrings installation guide.

Ideal For




Gravelrings - the hidden secret

Unlike any other gravel retention grid system, Beauxfort’s Gravelrings has been designed to provide hidden, but effective, gravel driveway support. At just 25mm deep, Gravelrings gravel mats for driveways ...

Learn More

How Gravelrings works

The Gravelrings gravel driveway retention system comprises interlocking gravel grid tiles made up of circular cells on a mesh base. The 25mm depth gravel mats are designed to be laid ...

Learn More

Overlaying an existing driveway with Gravelrings

Transform dull, flat tarmac driveways into beautiful gravel driveways with Gravelrings gravel driveway grids. Gravelrings can be used as an overlay system for tarmac driveways, by simply laying the gravel ...

Learn More

Gravelrings - the strength of the circle

Beauxfort’s Gravelrings gravel grid system utilises the strongest geometric shape to deliver the sturdiest gravel driveway grid design on the market, to deliver enduring performance and superior gravel driveway ...

Learn More


Panel size

500mm x 500mm*

*Comes supplied to site in a 1sqm tile

Panel Depth


Cell diameter


Gravel size (recommended)

6mm - 20mm (angular quarried aggregate only, marine washed, rounded and mixed aggregates should not be used)

Gravel demand

58 – 67kg per m²


100% recycled*, UV stabilised HDPE

* White panels are made from part-recycled materials


Chemical resistant


Black or White**

** Other colours available to order (subject to lead time and minimum order quantities)

Load Bearing capacity

350 tonnes per m²***

*** When filled with with 6-20mm angular gravel to a depth of 15mm above the top of the cells


Gravelrings can be laid on slopes depending on the gradient - contact our sales team for advice

How to install Gravelrings

Discover Beauxfort’s range of unique landscape products

Gravelrings grid system for gravel driveways, Grassrings grass protection system, and Groundcell erosion control and tree root protection landscape systems.
