Gravelrings gravel grids
for strong, stable,
stone migration free
surfaces

Gravel retention system

Beauxfort’s Gravelrings gravel driveway grid system creates a distinguished driveway that gives that all-important crunch-factor. The grids remain invisible beneath the surface as the system is designed to be overfilled, delivering porous, stable and dependable gravel driveway support for demanding use.

• Reduces project costs as the system requires less gravel demand and excavation than alternative systems

• Fast installation, Gravelrings gravel driveway grids come prepared in 1sqm tiles with a simple clipping mechanism making the system extremely efficient to lay

• Stops stone migration and patchy irregularities spoiling the beautiful aesthetic of gravel driveways

• Gravelrings gravel stabilisation system prevents gravel from slipping beneath the panels and lifting them up

Click here to download the Gravelrings installation guide.

Ideal For

Driveways

Landscaping

Pathways

Gravelrings - the hidden secret

Unlike any other gravel retention grid system, Beauxfort’s Gravelrings has been designed to provide hidden, but effective, gravel driveway support. At just 25mm deep, Gravelrings gravel mats for driveways ...

Learn More

How Gravelrings works

The Gravelrings gravel driveway retention system comprises interlocking gravel grid tiles made up of circular cells on a mesh base. The 25mm depth gravel mats are designed to be laid ...

Learn More

Overlaying an existing driveway with Gravelrings

Transform dull, flat tarmac driveways into beautiful gravel driveways with Gravelrings gravel driveway grids. Gravelrings can be used as an overlay system for tarmac driveways, by simply laying the gravel ...

Learn More

Gravelrings - the strength of the circle

Beauxfort’s Gravelrings gravel grid system utilises the strongest geometric shape to deliver the sturdiest gravel driveway grid design on the market, to deliver enduring performance and superior gravel driveway ...

Learn More

Technical
information

Panel size

500mm x 500mm

Panel Depth

25mm

Cell diameter

50mm

Gravel size (recommended)

6mm - 20mm (angular quarried aggregate only, marine washed, rounded and mixed aggregates should not be used)

Gravel demand

58 – 67kg per m²

Material

100% recycled*, UV stabilised HDPE

* White panels are made from part-recycled materials

Resistance

Chemical resistant

Colour

Black or White**

** Other colours available to order (subject to lead time and minimum order quantities)

Load Bearing capacity

350 tonnes per m²***

*** When filled with with 6-20mm angular gravel to a depth of 15mm above the top of the cells

Gradients

Gravelrings can be laid on slopes depending on the gradient - contact our sales team for advice

How to install Gravelrings
